Principle overview：
This series of crusher has following advantages compared to other fine crushers.
1. After nearly ten years application and improvement, it has been proved that this series crusher crushing effect is remarkable, durable, stand the market test.
2. Among very fine products, the particle size less than 8mm accounted for 50%.
3. Zero friction crushing , Long life of jaw plate , hundreds tons of minerals only use 2kg the steel consumption (including residual panel) , general jaw plate life lasts 45-60 days.
4. High cost performance, compared to other fine crushers, the price is low 1/4-1/2 and the maintenance cost is 1/3-1/5
5. More crushing and less grinding benefits significantly, the same grinder can increase 15-30% processing capacity.
6. Independent design separate thin oil lubricating station, the safely transmission arm with overload protection
Selection instructions：
It suited for crushing coal, gypsum, alum, limestone etc, the compressive strength of the material does not exceed 1000kg/cm2, humidity is not more than 15%.
Technical Parameters：
Model | Rotation diameter (mm) | Outlet size(mm) | Maximum feed size(mm) | Production capacity(t/h) | Power (kW) |
| PC-中600 x 400 | 中600 | 10-30 | 100 | 12-15 | 18.5 |
| PC-中600 x 600 | 中600 | 10-30 | 100 | 12-18 | 30 |
| PC-中800 x 700 | 中800 | 10-45 | 200 | 13-35 | 37 |
| PC-中800 x 800 | 中800 | 10-45 | 200 | 13-40 | 37 |
| PC-中 1000 x 1000 | 中1000 | 8-60 | 300 | 30-80 | 55 |
| PC-中 1000 x 1300 | 中1000 | 8-60 | 200 | 35-100 | 110 |
| PC-中 1000 x 1500 | 中1000 | 8-60 | 300 | 40-100 | 132 |
| PC-中 1200 x 1600 | 中1200 | 10-70 | 500 | 100 - 250 | 160 |
